D17.0x H10.0mm with holder .HX-15PH series of lenses, measuring less than 17 mm in diameter and less than 10 mm tall, All subfamilies have the same dimensions and come preassembled in lightweight durable holders with fastening tape that makes their installation fast and easy. HX-15PH family has a wide selection of beams from narrow to wide flood.
Diameter 17.0mm easily sealable TIR-lenses for up to 3535 ,3030,2525 size LED packages.
For example :
CREE XP-E,XP-G/G2,XP-L,XT-E;
CREE XB-D,XQ-E;
OSRAM SSL80,SSL150,Square;
Seoul Z5P,Z5M;
Luxeon T,Federal 3535;
LG 3535, Samsung 3535;
Nichia 119A;
| # | Part No.(Model) | DIM(mm) | FWHM(deg) | For LEDs | Material | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | HX-15PH-15 | D17.0 * H10.0 | 12° | 2525,3030,3535 LEDs | PC +PMMA | |||||
| 2 | HX-15PH-25L | D17.0 * H10.0 | 25° | 2525,3030,3535 LEDs | PC +PMMA | |||||
| 3 | HX-15PH-30L | D17.0 * H10.0 | 30° | 2525,3030,3535 LEDs | PC +PMMA | |||||
| 4 | HX-15PH-45L | D17.0 * H10.0 | 45° | 2525,3030,3535 LEDs | PC +PMMA | |||||
| 5 | HX-15PH-60L | D17.0 * H10.0 | 60° | 2525,3030,3535 LEDs | PC +PMMA | |||||
| 6 | HX-15PH-1545 | D17.0 * H10.0 | 15(±5) x 45(±5) | 2525,3030,3535 LEDs | PC +PMMA | |||||
| 7 | HX-15PHB-15 | D17.0 * H10.0 | 12° | 2525,3030 LEDs | PC +PMMA | |||||
| 8 | HX-15PHB-25L | D17.0 * H10.0 | 25° | 2525,3030 LEDs | PC +PMMA | |||||
| 9 | HX-15PHB-30L | D17.0 * H10.0 | 30° | 2525,3030 LEDs | PC +PMMA | |||||
| 10 | HX-15PHB-45L | D17.0 * H10.0 | 45° | 2525,3030 LEDs | PC +PMMA | |||||
| 11 | HX-15PHB-60L | D17.0 * H10.0 | 60° | 2525,3030 LEDs | PC +PMMA | |||||
| 12 | HX-15PHB-1545 | D17.0 * H10.0 | 15(±5) x 45(±5) | 2525,3030 LEDs | PC +PMMA |
