23~ 35.8mm 3H1 arrays 50 x 50 mm led lens for 3030 3535 5050 size LED packages for flood lights,tunnel lights,stadium lights,parking lot lighting,high bay lighting.( HX-F50 Series )

HX-F50 Series optics (50x50mm 2X2 arrays) ensure optimal lighting conditions for both players and spectators that meet the standards and requirements of different sports,for flood lights,tunnel lights,stadium lights,parking lot lighting.Beams are designed for symmetrical and asymmetrical low glare sports floodlights. Optimized for HP 3535 and compatible with up to 5050 size flat LED packages.


Product Description

HX-F50 Series optics (50x50mm 2X2 arrays) ensure optimal lighting conditions for both players and spectators that meet the standards and requirements of different sports,for flood lights,tunnel lights,stadium lights,parking lot lighting high bay lighting.Beams are designed for symmetrical and asymmetrical low glare sports floodlights. Optimized for HP 3535 and compatible with up to 5050 size flat LED packages.
For example :
CREE XP-E,XP-G/G2,XP-L,XT-E,XHP35;
CREE XML,MHB;
OSRAM SSL80,SSL150,Square,P8,S8;
Seoul Z5P,Z5M;
Luxeon T,Federal 3535,5050;
LG 3535, Samsung 3535;
Nichia 119A;
3030,3535,5050,7070 ;



No. Part No.(Model) DIM(mm) Angle(deg) For LEDs Material
1 HX-10-15L D10.65 * H6.8 15° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
2 HX-10-30L D10.65 * H6.8 30° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
3 HX-10-45L D10.65 * H6.8 45° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
4 HX-10-60L D10.65 * H6.8 60° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
5 HX-10-90L D10.65 * H6.8 90° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA

CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS
CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS
CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS
CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS
