3-LINEAR arrays 50 x 50 mm led lens for 3030 3535 5050 size LED packages for flood lights,tunnel lights,stadium lights,parking lot lighting,high bay lighting.( HX-F50 Series )

HX-F50 Series optics (50x50mm 2X2 arrays) ensure optimal lighting conditions for both players and spectators that meet the standards and requirements of different sports,for flood lights,tunnel lights,stadium lights,parking lot lighting.Beams are designed for symmetrical and asymmetrical low glare sports floodlights. Optimized for HP 3535 and compatible with up to 5050 size flat LED packages.


Product Description

HX-F50 Series optics (50x50mm 2X2 arrays) ensure optimal lighting conditions for both players and spectators that meet the standards and requirements of different sports,for flood lights,tunnel lights,stadium lights,parking lot lighting high bay lighting.Beams are designed for symmetrical and asymmetrical low glare sports floodlights. Optimized for HP 3535 and compatible with up to 5050 size flat LED packages.
For example :
CREE XP-E,XP-G/G2,XP-L,XT-E,XHP35;
CREE XML,MHB;
OSRAM SSL80,SSL150,Square,P8,S8;
Seoul Z5P,Z5M;
Luxeon T,Federal 3535,5050;
LG 3535, Samsung 3535;
Nichia 119A;
3030,3535,5050,7070 ;



No. Part No.(Model) DIM(mm) Angle(deg) For LEDs Material
1 HX-10-15L D10.65 * H6.8 15° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
2 HX-10-30L D10.65 * H6.8 30° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
3 HX-10-45L D10.65 * H6.8 45° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
4 HX-10-60L D10.65 * H6.8 60° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA
5 HX-10-90L D10.65 * H6.8 90° CREE XPE,OSRAM OSLON,3030,3535 LEDs PC +PMMA

CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS
CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS
CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS
CREE XP XHP35 XML MHB OSRAM P8 S8 flood lights tunnel lights stadium lights parking lot lighting high bay lighting LED LENS

Product Download

Product Application

3. High Bay Light: 300W UFO LED High Bay The 300W UFO high bay light emits 45,000lm at 6500K daylight, replacing 600W HID fixtures in warehouses, sports arenas, or manufacturing plants. With a 120° beam angle and IP66 waterproof rating, it withstands dust and water jets. Technical specs: 150lm/W efficiency, 100-277V AC input, and 100,000-hour lifespan. The aluminum heat sink reduces maintenance costs by 70% compared to traditional lighting. 4. Digital Microscope: 4K USB Digital Microscope This 4K digital microscope (3840x2160 resolution) offers 20-2000X magnification via a 12MP sensor, connecting to PCs/tablets for real-time 4K video recording. Equipped with 16 adjustable LED lights and a 3D measurement function, it features a flexible stand for 360° viewing. Technical features: 0.1mm depth of field, 5-30cm working distance, and compatibility with Windows/macOS/Linux. Ideal for electronics repair, semiconductor inspection, or educational research.

5. Lighting Accessories: LED Reflector with Diffuser This combo lighting accessory pairs an aluminum reflector (95% reflectivity) with a PMMA diffuser (90% transmittance), softening LED light for uniform illumination. Compatible with 5050 SMD strips, it reduces glare while enhancing light output by 60%. Technical specs: 10mm thickness, heat resistance up to 90°C, and snap-fit installation. Suitable for office panels, retail displays, or home ceiling lights. 6. Lamp Holder: E27 Ceramic Lamp Holder Engineered for high-power bulbs, this E27 ceramic lamp holder supports up to 200W loads and withstands temperatures up to 300°C. The brass contacts ensure stable conductivity, while the fire-resistant ceramic body meets UL94 V-0 standards. Technical details: 100-240V AC compatibility, 3A current rating, and 2.5kg weight capacity. Ideal for industrial fixtures, halogen lamps, or high-heat environments.

7. Spotlight LED: 20W COB Spotlight with Lens The 20W COB spotlight delivers 1600lm at 3000K warm white, featuring a 15° PMMA lens for precise beam control. The die-cast aluminum housing ensures efficient heat dissipation, supporting 50,000-hour lifespan. Technical specs: 85-265V AC input, 95+ CRI, and DMX512 dimming. Perfect for art galleries, retail showcases, or restaurant accent lighting. 8. LED Lens: 3535 SMD 60° Optical Lens Designed for 3535 SMD LEDs, this 60° PMMA lens features micro-prism structure for uniform light distribution, reducing hotspots by 80%. The rectangular design (8mm x 4mm) fits standard PCB layouts, with 92% light transmittance. Technical specs: ±0.05mm tolerance, UV-stabilized material, and reflow soldering compatibility. Ideal for LED tubes, panels, or linear lighting systems.
