3~80 degree Diameter 50 to 210mm Dimmable Lighting LED lens for CREE | OSRAM | Citizen | Bridgelux COB LEDs (HX-CDxx Series).

Dimmable Lighting PMMA PC optics LED lens. The HX-CDxx Series of lenses: all subfamilies have the same dimensions and come preassembled in lightweight, durable holders with fastening tape that makes their installation fast and easy. The HX-CDxx Series family has a wide selection of beams from narrow to wide flood. Perfectly compatible with COB LEDs such as Bridgelux, Citizen, Cree, Osram, Samsung, Lumileds, LEXTAR, etc. Widely used in basketball court lighting, gymnasium lighting, badminton court lighting, volleyball court lighting, underwater lighting, outdoor landscape lighting (or lens), security equipment, traffic display lighting (or lens), electronic components, automotive lamp lenses, beam lamp lenses, and stage lighting.


Product Description

3~80 degree Diameter 50 to 210mm Dimmable Lighting LED lens for CREE | OSRAM | Citizen | Bridgelux COB LEDs

Product Selection Guide :

led lenses, Glass Lenses, Fresnel lens, Streetlight lens

Product Download

Product Application

5. Lighting Accessories: LED Reflector with Diffuser This combo lighting accessory pairs an aluminum reflector (95% reflectivity) with a PMMA diffuser (90% transmittance), softening LED light for uniform illumination. Compatible with 5050 SMD strips, it reduces glare while enhancing light output by 60%. Technical specs: 10mm thickness, heat resistance up to 90°C, and snap-fit installation. Suitable for office panels, retail displays, or home ceiling lights. 6. Lamp Holder: E27 Ceramic Lamp Holder Engineered for high-power bulbs, this E27 ceramic lamp holder supports up to 200W loads and withstands temperatures up to 300°C. The brass contacts ensure stable conductivity, while the fire-resistant ceramic body meets UL94 V-0 standards. Technical details: 100-240V AC compatibility, 3A current rating, and 2.5kg weight capacity. Ideal for industrial fixtures, halogen lamps, or high-heat environments.

The Hongxuan(Shenzhen Hongxuan Optoelectronic Technology Co.,Ltd) lens offers low-profile lenses specifically designed for the Luxeon LEDs, OSRAM LEDs ,Bridgelux LEDs or Seoul LEDs,Cree LEDs. A software-optimized aspheric profile enables the generation of several different beam output patterns:narrow,medium,elliptical and wides beams. The high collection efficiency reaches 85% of the total flux emitted by the LEDs. Lens holders are available in white or black,and provide the proper alignment the between the LEDs and the lenses,set correct distance between the lens and LED. The lens holder can be glued to the PCB to provide a secure assembly.

The LED lenses are for CREE,Lumileds,Osram,Seoul,Nichia,Bridgelux,Citizen,Prolight LEDs.and can provide street light lens,flood light lens,lighting lens,MR16 lens,Par22 lens,Par30 lens,Par38 lens,stage lighting lens,flashlight lens,hybrid light lens. These TIR optics are used to get narrow beams with smaller LED's or allow you to use the larger source LED’s and even multi chip LED's. As with the other TIR ranges, we have a number of beams to allow you to use the same size optics for a number of beam angles.
